Siemens ED42B060 - Molded Case Circuit Breaker 60A 480V 2-Pole
Siemens ED42B060 - Molded Case Circuit Breaker 60A 480V 2-Pole

Siemens ED42B060 - Molded Case Circuit Breaker 60A 480V 2-Pole

Siemens
Price
Save $1,529.63
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens ED42B060 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 60A current rating and a 480V AC voltage rating, housed within a compact 125A/ED frame with dimensions of 6.693" x 5.906" x 2.772" and a weight of 0.278 lb. The breaker is constructed with thermal-magnetic trip protection for both long-time delay and instantaneous tripping functions, ensuring compliance with IEC and UL standards. It is engineered for installation in SB switchboards and Sentron panelboards, supporting a wide operating temperature range from -25°C to 70°C and accepting wire sizes from 10 to 1/0 AWG for aluminum or copper conductors.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Standard, Thermal-Magnetic Protection
  • Voltage Rating: 480V AC
  • Current Rating: 60A
  • Frame Size: 125A/ED
  • Poles: 2
  • AIC Rating: 18kA at 480V
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Connection: Lug In Panelboard, Load Side Lug
  • Wire Size: 10 to 1/0 AWG (Aluminum/Copper)
  • Phase: 1, Phase Connection: Any
  • Panel Type: SB Switchboards, Sentron Panelboards
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 6.693" x 5.906" x 2.772"
  • Weight: 0.278 lb
  • Standards & Certification: IEC Certified, UL Listed
  • Breaker Type: Standard
  • Protection: Thermal Magnetic
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643209299
  • GTIN: 00783643209299
