Siemens ED42B050 - Molded Case Breaker 50A 480V 2-Pole
Siemens ED42B050 - Molded Case Breaker 50A 480V 2-Pole

Siemens ED42B050 - Molded Case Breaker 50A 480V 2-Pole

Siemens
Price
Save $1,750.70
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens ED42B050 is a molded case circuit breaker designed for providing reliable overcurrent protection in single-phase industrial electrical systems. It features a 50A current rating and a 480V AC voltage rating, housed within a compact 125A/ED frame with dimensions of 6.693" x 5.906" x 2.770" (170mm x 150mm x 70.4mm) and a weight of 0.258 lb. The breaker is UL Listed and HACR rated, ensuring compliance with industry safety standards for use in SB switchboards and Sentron panelboards. Its thermal-magnetic protection with long-time and instantaneous (LI) trip functions makes it suitable for safeguarding branch circuits and equipment against overloads and short circuits.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Standard, Thermal-Magnetic Protection
  • Voltage Rating: 480V AC
  • Current Rating: 50A
  • Frame Size: 125A/ED
  • AIC Rating: 18kA at 480V
  • Poles: 2
  • Phase: 1
  • Connection: Lug in Panelboard, Load Side Lug
  • Trip Functions: LI (Long-Time and Instantaneous)
  • Panel Type: SB Switchboards, Sentron Panelboards
  • Phase Connection: Any
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • MCM Size: Min. Wire Size 10 AWG, Max. Wire Size 1/0 AWG
  • Dimensions: 6.693" x 5.906" x 2.770" (170mm x 150mm x 70.4mm)
  • Weight: 0.258 lb
  • Standards & Certification: HACR Rated, UL Listed
  • Country of Origin: Mexico
  • Family: Sentron Series


Product Identification
  • UPC: 783643209282
  • GTIN: 00783643209282
