Siemens ED42B030 - Molded Case Circuit Breaker 30A 480V 2-Pole
Siemens ED42B030 - Molded Case Circuit Breaker 30A 480V 2-Pole

Siemens ED42B030 - Molded Case Circuit Breaker 30A 480V 2-Pole

Siemens
Price
Save $1,576.21
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens ED42B030 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in commercial and industrial electrical systems. It features a 30A current rating and a 480V AC voltage rating, housed within a compact, durable frame measuring 7.283" x 2.953" x 5.512" (185mm x 75mm x 140mm) and weighing 2.571 lb. This thermal-magnetic breaker is HACR rated and UL listed, ensuring compliance with industry safety standards for use in SB switchboards and Sentron panelboards. Its robust construction supports a wide operating temperature range from -25°C to 70°C and is engineered for single-phase applications requiring an interrupting capacity of 18kA at 480V.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection with Long-Time and Instantaneous (LI) Trip Functions
  • Voltage Rating: 480V AC
  • Current Rating: 30A
  • Frame Size: 125A/ED
  • Poles: 2
  • AIC Rating: 18kA @ 480V
  • Connection: Load Side Lug, Lug in Panelboard
  • Wire Size: 10 to 1/0 AWG (Aluminum/Copper)
  • Phase: 1, Any Phase Connection
  • Standards/Certification: HACR Rated, UL Listed
  • Panel Type: Compatible with SB Switchboards and Sentron Panelboards
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 7.283 x 2.953 x 5.512 inch (185 x 75 x 140 mm)
  • Weight: 2.571 lb
  • Breaker Type: Standard
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous)
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643209244
  • GTIN: 00783643209244
