Eaton ED3150V is a three-pole molded case circuit breaker designed for overcurrent protection in industrial power distribution systems. It is rated for 480V AC and 150A continuous current, providing reliable fault interruption. The unit measures 3.38 inches in depth, 6 inches in height, and 4.13 inches in width, weighing 4.5 lb, with a compact thermoplastic construction suitable for panelboard mounting. This breaker complies with UL 489 and CSA C22.2 standards, ensuring safety and performance in demanding environments. Typical applications include motor control centers, lighting panels, and feeder circuits in manufacturing plants and commercial buildings.

Key Features & Specifications
  • Type: Molded case circuit breaker, three-pole, thermal-magnetic trip
  • Voltage Rating: 480V AC
  • Current Rating: 150A
  • Dimensions: 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
  • Standards: UL 489, CSA C22.2
  • Applications: Industrial power distribution, motor control centers, lighting panels
  • Switch Type: Toggle
  • Configuration: Three-pole
  • Coil Voltage Maximum: Not applicable (thermal-magnetic)
  • Temp Rating: 40°C ambient
  • Shipping Dimensions: 3.38 in x 6 in x 4.13 in
  • Phase: Three-phase
  • Voltage: 480V AC
  • Amperage: 150A
  • AIC rating: 25 kAIC at 480V AC
  • Connection: Line and load lugs
  • Poles: 3
  • Protection: Overcurrent and short-circuit
  • Functions: Overload and short-circuit protection
  • Frame Size: ED
  • Trip Type: Thermal-magnetic
  • Panel Type: Panelboard
  • Breaker Type: Molded case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: 250 kcmil max
  • Metal Type: Copper alloy contacts
  • Panel Style: Flush mount
  • Bus Type: Copper
  • Fuse Class: Not applicable
  • Insulation Temperature: 105°C
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Panelboard
  • Hz: 50/60 Hz
  • Coil Material: Not applicable
  • Horse Power: 100 HP at 480V AC
  • Aux Contacts: Optional
  • CPT: Not included
  • Full Load Amps: 150A
  • Dist Voltage: 480V AC
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 150A
  • Full Load Amp Minimum: 150A
  • Enclosure: Open
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Copper or aluminum
  • Amperage Maximum: 150A
  • Amperage Minimum: 150A
  • Nema Rating: 1
  • Switch Style: Toggle
  • Wire Size: 14 AWG to 250 kcmil
  • Certification: UL, CSA
  • Circuit Breaker Mounting Style: Bolt-on
  • Terminal Connection: Lug
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Three-phase
  • Standards: UL 489, CSA C22.2
  • Compatible Frames: ED frame
  • Installation Type: Panelboard
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: ED
  • Current Rating: 150A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not applicable
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 40°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable
