Cutler Hammer
Price
Save $1,642.35
/
Condition
  • Low stock - 5 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer ED3150 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power systems. It features a 150A continuous current rating and a 240V AC voltage rating, housed within a compact, bolt-on frame measuring 3.38" D x 6" H x 4.13" W and weighing 4.5 lb. The breaker is constructed with thermal-magnetic trip technology for long-time and instantaneous (LI) protection, achieving a 65kA interrupting rating at 240V, and complies with UL, CSA, and IEC standards. Its robust design supports a wide operating temperature range from -4°F to 158°F, making it suitable for installation in motor control centers, switchboards, and enclosed control panels from major manufacturers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Trip, Bolt-On Connection
  • Voltage Rating: 240V AC
  • Current Rating: 150A
  • Frame Size: 225A/F
  • Poles: 3
  • AIC Rating: 65kA @ 240V
  • Phase Connection: 3-Phase, ABC
  • Protection Functions: Long-Time & Instantaneous (LI)
  • Connection: Bolt-On, Load Side Lug Terminal
  • Wire Size Range: 14 AWG to 1/0 AWG
  • Operating Temperature: -4°F to 158°F (-20°C to 70°C)
  • Dimensions: 3.38 in (D) x 6 in (H) x 4.13 in (W)
  • Weight: 4.5 lb
  • Standards & Certification: UL Listed, CSA Certified, IEC Rated
  • Compatible Panel Types: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Breaker Type: Standard
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679455265
  • GTIN: 00786679455265
