Cutler Hammer ED2100 - Molded Case Circuit Breaker 100A 2P (65kA AIC)
Cutler Hammer ED2100 - Molded Case Circuit Breaker 100A 2P (65kA AIC)
Cutler Hammer ED2100 - Molded Case Circuit Breaker 100A 2P (65kA AIC)
Cutler Hammer ED2100 - Molded Case Circuit Breaker 100A 2P (65kA AIC)

Cutler Hammer ED2100 - Molded Case Circuit Breaker 100A 2P (65kA AIC)

Cutler Hammer
Price
Save $486.90
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer ED2100 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 100A current rating and a 240V AC voltage rating, housed within a compact F-frame measuring 3.38 in (D) x 6 in (H) x 2.75 in (W) and weighing 2.9 lb. This UL Listed device utilizes a thermal-magnetic trip unit with long-time and instantaneous (LI) functions to ensure protection across a wide operating temperature range of -25°C to 70°C (-13°F to 158°F). Its 65kA interrupting capacity at 240V and feed-thru connection make it suitable for safeguarding branch circuits and equipment in panelboards and switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Series C Family
  • Voltage Rating: 240V AC
  • Current Rating: 100A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 2.75 in (Width)
  • Standards: UL Listed
  • Applications: Industrial and Commercial Panelboards, Switchboards, Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 2
  • Amperage: 100A
  • AIC Rating: 65kA @ 240V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip (LI)
  • Frame Size: F Frame
  • Trip Type: Thermal Magnetic
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 2.9 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679456460
  • GTIN: 00786679456460
