Edison Fuses ECNR0.6 - Class CC Fuse 0.6A 250V
Edison Fuses ECNR0.6 - Class CC Fuse 0.6A 250V

Edison Fuses ECNR0.6 - Class CC Fuse 0.6A 250V

Edison Fuses
Price
Save $-11.78
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Edison Fuses ECNR0.6 is a time-delay, dual-element fuse designed for the protection of motor circuits and other inductive loads against short circuits and overloads. This 0.6 amp, 250-volt AC/DC rated fuse provides a 200,000 amp interrupting capacity, ensuring robust fault current protection. Constructed with a compact, rejection-style body for Class CC fuse holders, it features a non-renewable design with a glass melamine tube and silver-plated end caps. The fuse complies with UL 248-4 and CSA C22.2 standards, making it suitable for industrial control panels, motor starters, and transformer protection applications.

Key Features & Specifications
  • Type: Class CC, time-delay, dual-element, non-renewable fuse with glass melamine tube and silver-plated end caps
  • Voltage Rating: 250 V AC/DC
  • Current Rating: 0.6 A
  • AIC Rating: 200,000 A
  • Dimensions: 13/32" diameter x 1-1/2" length
  • Standards: UL 248-4, CSA C22.2
  • Applications: Motor circuit protection, transformer protection, control panel protection
  • Weight: 5.19 lb


Product Identification
  • UPC: 782001904407
