Cutler Hammer E34TPB120 - 1-Pole 20A Circuit Breaker (120V AC)
Cutler Hammer E34TPB120 - 1-Pole 20A Circuit Breaker (120V AC)

Cutler Hammer E34TPB120 - 1-Pole 20A Circuit Breaker (120V AC)

Cutler Hammer
Price
Save $75.42
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer E34TPB120 is a molded case circuit breaker designed for overcurrent protection in industrial power distribution systems. It is rated for 120V AC and carries a current rating of 20 amps, providing reliable short-circuit and overload protection. The unit measures 3.5 inches in length, 3.5 inches in height, and 2.5 inches in width, with a weight of 0.4 lb, featuring a compact, durable construction suitable for panelboard installation. This breaker complies with UL and NEMA standards for safety and performance in commercial and industrial environments. Typical applications include motor control centers, lighting panels, and branch circuit protection in manufacturing facilities.

Key Features & Specifications
  • Type: Molded case circuit breaker, thermal-magnetic trip
  • Voltage Rating: 120V AC
  • Current Rating: 20 A
  • Dimensions: 3.5 in x 3.5 in x 2.5 in (Length/Depth x Height x Width)
  • Weight: 0.4 lb
  • Standards: UL 489, NEMA AB-1
  • Applications: Industrial power distribution, motor control, branch circuit protection
  • Poles: 1
  • Frame Size: E34
  • Trip Type: Thermal-magnetic
  • Breaker Type: Molded case
  • Connection: Line and load terminals
  • Mounting: Panel mount
  • Frequency Rating: 60 Hz
  • Phase: 1
  • AIC Rating: 10 kAIC @ 120V AC
  • Wire Size: #14 AWG to #8 AWG
  • Terminal Connection: Screw type
  • Insulation Temperature: 75°C
  • Operating Temperature Maximum Celsius: 40°C


Product Identification
  • UPC: 78211370536
  • GTIN: 00782113705361
