Cutler Hammer E30KJ13 - 3-Pole 30A 600V AC Circuit Breaker
Cutler Hammer E30KJ13 - 3-Pole 30A 600V AC Circuit Breaker

Cutler Hammer E30KJ13 - 3-Pole 30A 600V AC Circuit Breaker

Cutler Hammer
Price
Save $3.98
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler Hammer E30KJ13 is a molded case circuit breaker designed for overcurrent protection and electrical isolation in industrial power distribution systems. It is rated for 30 amps at 600 volts AC, with a 10 kAIC interrupting capacity, and features a 3-pole configuration with a thermal-magnetic trip mechanism for precise overload and short-circuit response. This compact unit measures 5 inches in depth, 0.5 inches in height, and 4 inches in width, weighing 0.1 lb, and is constructed with a durable thermoplastic housing and line/load side lug terminals. It complies with UL 489 and CSA C22.2 standards, ensuring reliable performance in commercial and industrial environments. Typical applications include motor control centers, panelboards, and switchboards requiring branch circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, thermal-magnetic trip, thermoplastic housing
  • Voltage Rating: 600 V AC
  • Current Rating: 30 A
  • Dimensions: 5 in x 0.5 in x 4 in (Length/Depth x Height x Width)
  • Standards: UL 489, CSA C22.2
  • Applications: Motor control centers, panelboards, switchboards
  • Poles: 3
  • AIC Rating: 10 kAIC
  • Trip Type: Thermal-magnetic
  • Connection: Line/load side lugs
  • Frame Size: E-frame
  • Phase: 3-phase
  • Frequency Rating: 50/60 Hz
  • Operating Temperature Maximum Celsius: 40 °C
  • Weight: 0.1 lb


Product Identification
  • UPC: 078211321797
  • GTIN: 00782113217970
