Cutler Hammer E10T215GS - 2-Pole 15A Miniature Breaker (10 kAIC)
Cutler Hammer E10T215GS - 2-Pole 15A Miniature Breaker (10 kAIC)

Cutler Hammer E10T215GS - 2-Pole 15A Miniature Breaker (10 kAIC)

Cutler Hammer
Price
Save $2.14
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer E10T215GS is a 2-pole, 15-amp miniature circuit breaker designed for overcurrent protection in branch circuits. It operates at 120/240 VAC with a 10 kAIC interrupting rating, housed in a compact 1.3-inch depth, 2.2-inch height, and 0.7-inch width molded case weighing 0.09 lb. The unit features a thermal-magnetic trip mechanism for both overload and short-circuit protection, with a standard bolt-on mounting style and screw-type terminal connections. It is UL 489 listed and CSA certified for compliance with North American electrical safety standards. This breaker is typically used in Cutler Hammer CH load centers and panelboards for residential and light commercial applications.

Key Features & Specifications
  • Type: Miniature circuit breaker, thermal-magnetic trip, bolt-on mounting
  • Voltage Rating: 120/240 VAC
  • Current Rating: 15 A
  • Dimensions: 1.3 in x 2.2 in x 0.7 in (Length/Depth x Height x Width)
  • Standards: UL 489, CSA certified
  • Applications: Branch circuit protection in residential and light commercial panelboards
  • Poles: 2
  • AIC Rating: 10 kAIC at 120/240 VAC
  • Connection: Screw terminals
  • Protection: Overload and short-circuit
  • Frame Size: CH
  • Trip Type: Thermal-magnetic
  • Breaker Type: E10T215GS
  • Circuit Breaker Mounting Style: Bolt-on
  • Terminal Connection: Screw
  • Frequency Rating: 60 Hz
  • Phase Connection: Single-phase
  • Weight: 0.09 lb


Product Identification
  • UPC: 78211369841
  • GTIN: 00782113698410
