Siemens DTNF321 - Non-Fusible Disconnect Switch 240V AC 30A (200kA AIC @240V)

Siemens DTNF321 is a non-fusible disconnect switch designed for safe electrical isolation in industrial applications, featuring a 240V AC voltage rating and 30A current capacity. The rugged NEMA 1-rated enclosure measures 11.5 x 25.0 inches with a 54 lb weight, constructed for durability in demanding environments. UL98-certified with 200kA AIC protection at 240V, this 3-phase switch meets stringent safety standards for circuit interruption. Its single-configuration, 3-pole design is compatible with MAP frames, making it ideal for motor control centers and power distribution systems requiring reliable load breaking.

Key Features & Specifications

• Type: Non-fusible disconnect switch (DTNF), VBII Series
• Voltage Rating: 240V AC
• Current Rating: 30A
• Dimensions: 11.5 x 25.0 inches
• Standards: UL98, NEMA 1
• Applications: Motor control centers, power distribution
• Configuration: Single
• Poles: 3
• AIC rating: 200kA@240V
• Phase: 3
• Weight: 54 lb
• Compatible Frames: MAP
• Country of Origin: Mexico

Product Identification

• UPC: 783643454132
• GTIN: 00783643454132
