Eaton DS454 - Class J Fuse 600V/600A (200kA Interrupt Rating)

Eaton DS454 is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 600V AC voltage rating and current ratings up to 600A, housed in a durable cylindrical ceramic body with silver-plated copper end caps for optimal conductivity. The fuse meets UL 248-12 and IEC 60269 standards, ensuring reliable performance in demanding environments like motor control centers, transformers, and switchgear applications.

Key Features & Specifications

• Type: Current-limiting Class J fuse with ceramic body and silver-plated terminals
• Voltage Rating: 600V AC
• Current Rating: 600A (range 70-600A available)
• Dimensions: 76.2mm diameter x 146.05mm length
• Standards: UL 248-12, IEC 60269 compliant
• Applications: Motor protection, transformer circuits, industrial switchgear
• Interrupt Rating: 200kA symmetrical
• Operating Temperature: -50°C to +125°C
• Weight: 3.26 lb

Product Identification

• UPC: 782274775647
• GTIN: 00782274775647
