Eaton DRS20/125B5 - Medium Voltage DIN Fuse 125A (25.8kV Class E)
Eaton DRS20/125B5 - Medium Voltage DIN Fuse 125A (25.8kV Class E)
Eaton DRS20/125B5 - Medium Voltage DIN Fuse 125A (25.8kV Class E)
Eaton DRS20/125B5 - Medium Voltage DIN Fuse 125A (25.8kV Class E)

Eaton DRS20/125B5 - Medium Voltage DIN Fuse 125A (25.8kV Class E)

Eaton
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton DRS20/125B5 is a medium voltage DIN fuse designed for industrial circuit protection applications. This fuse features a 25.8kV voltage rating and 125A current rating for reliable overcurrent protection in demanding environments. Constructed with a single-barrel design measuring 1.77 inches in diameter and featuring 22.2mm clip center spacing, the unit utilizes DIN connection compatibility for standardized installation. The Class E rated fuse meets international industrial standards for medium voltage applications, making it suitable for power distribution systems, industrial control panels, and heavy machinery protection where robust electrical safeguarding is required.

Key Features & Specifications
  • Type: Medium voltage DIN fuse, single barrel construction
  • Voltage Rating: 25.8kV
  • Current Rating: 125A
  • Dimensions: 1.77" diameter, 22.2mm clip center spacing
  • Weight: 14 lb
  • Class Rating: E
  • Connection: DIN standard
  • Barrels: 1
  • Item Subcategory: Medium Voltage
