Bussmann DLS-R-125 - RK5 Time-Delay Fuse 125A (200kA AIC @ 600V)

Bussmann DLS-R-125 is a current-limiting fuse designed for robust overcurrent protection in demanding industrial electrical systems. It features a 125A current rating and 600V voltage rating, providing reliable circuit interruption capabilities. The fuse utilizes a single-barrel construction with RK5 classification, ensuring high interrupting capacity and time-delay characteristics for motor circuit applications. Certified to UL and CSA standards, this fuse meets rigorous safety and performance requirements for industrial use. Typical applications include motor branch circuit protection, industrial control panels, and power distribution equipment where 200kA interrupting rating at 600V is required.

Key Features & Specifications

• Type: Current-limiting time-delay fuse, RK5 class, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 125A
• Dimensions: Standard DLS-R series dimensions
• Standards: UL, CSA certified
• Applications: Motor branch circuits, industrial control panels, power distribution systems
• AIC rating: 200kA@600V
• Class Rating: RK5
• Barrels: 1
• Weight: 1 lb
• Family: Dura-Lag
• Item Subcategory: Low Voltage

Product Identification

• GTIN: 00051712340342
