Bussmann DFJ-175 - Class J Time-Delay Fuse 175A (200kA Interrupting Rating)

Bussmann DFJ-175 is a Class J time-delay fuse designed for comprehensive circuit protection in industrial power distribution systems. It features a 600V AC voltage rating with a 175A current rating, providing reliable overcurrent protection. The fuse measures 5-3/4 inches in length with a single-barrel construction and weighs 1 lb. It complies with UL, CSA, and CE standards including UL File E4273 and CSA File 53787. Typical applications include motor branch circuits, feeders, and industrial control panels requiring high interrupting capacity.

Key Features & Specifications

• Type: Class J time-delay fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 175A
• Dimensions: 5-3/4 inches length
• Standards: UL Class J (Guide JDDZ, File E4273), CSA Class 1422-02 (File 53787), CE, 248-8
• Applications: Motor branch circuits, industrial feeders, control panels
• AIC rating: 200kA@600V
• Class Rating: J
• Barrels: 1
• Weight: 1 lb
• Certification: UL, CSA, CE

Product Identification

• UPC: 051712653459
• GTIN: 00051712653459
