Eaton DBU17-80E - Medium Voltage Fuse 80A @ 17kV (14kA AIC)

Eaton
Price
Save $-135.49
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton DBU17-80E is a medium voltage current-limiting fuse designed for the protection of transformers, motors, and feeders in industrial power distribution systems up to 17kV. It features a continuous current rating of 80A and an interrupting rating of 14kA at 17kV, housed within a robust, single-barrel ferrule-connected design with a 1.24-inch diameter and a total length of 19.1 inches. Constructed as a Class E fuse, it complies with the IEEE Std. C37.41 standard for design tests, ensuring reliable performance in demanding applications such as utility substations and large industrial facilities.

Key Features & Specifications
  • Type: DBU, Medium Voltage Current-Limiting Fuse, Single Barrel, Ferrule Connection
  • Voltage Rating: 17000V AC
  • Current Rating: 80A
  • Dimensions: 19.1 in L x 1.44 in H x 1.44 in W (1.24 in Diameter)
  • Weight: 2.13 lb
  • Standards: Certified to IEEE Std. C37.41
  • Applications: Protection for transformers, motors, and feeders in industrial power systems
  • Class Rating: E
  • AIC rating: 14kA @ 17kV
  • Connection: Ferrule
  • Barrels: 1
  • Velocity: Standard


Product Identification
  • UPC: 786676011082
  • GTIN: 00786676011082
