Cutler Hammer D80NE1E - 1-Pole 80A 600V Molded Case Breaker
Cutler Hammer D80NE1E - 1-Pole 80A 600V Molded Case Breaker

Cutler Hammer D80NE1E - 1-Pole 80A 600V Molded Case Breaker

Cutler Hammer
Price
Save $400.26
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer D80NE1E is a molded case circuit breaker designed for overcurrent and short-circuit protection in industrial power distribution systems. It is rated for 80 amps at 600 volts AC, with a 65 kAIC interrupting capacity at 240 VAC, and features a thermal-magnetic trip mechanism for precise overload and fault response. The unit has a compact frame size measuring 7.5 inches in depth, 4.75 inches in height, and 4.25 inches in width, weighing 1.9 lb, with a robust thermoplastic enclosure and line/load lug terminals for copper or aluminum conductors. It complies with UL 489 and CSA C22.2 standards, ensuring reliable performance in demanding environments. This breaker is commonly used in panelboards, switchboards, and motor control centers for commercial and industrial applications.

Key Features & Specifications
  • Type: Molded case circuit breaker, thermal-magnetic trip, thermoplastic enclosure
  • Voltage Rating: 600 VAC
  • Current Rating: 80 A
  • Dimensions: 7.5 in x 4.75 in x 4.25 in (Length/Depth x Height x Width)
  • Standards: UL 489, CSA C22.2
  • Applications: Panelboards, switchboards, motor control centers
  • Switch Type: Toggle
  • Configuration: 1-pole
  • Coil Voltage Maximum: Not applicable (thermal-magnetic)
  • Temp Rating: 40°C ambient
  • Shipping Dimensions: 7.5 in x 4.75 in x 4.25 in
  • Phase: 1-phase
  • Voltage: 600 VAC
  • Amperage: 80 A
  • AIC rating: 65 kAIC at 240 VAC
  • Connection: Line and load lugs
  • Poles: 1
  • Protection: Overcurrent and short-circuit
  • Functions: Thermal-magnetic trip
  • Frame Size: 100 A frame
  • Trip Type: Thermal-magnetic
  • Panel Type: Industrial
  • Breaker Type: Molded case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not specified
  • Metal Type: Copper/aluminum compatible
  • Panel Style: Standard
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: 105°C
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Panel mount
  • Hz: 50/60 Hz
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not included
  • CPT: Not included
  • Full Load Amps: 80 A
  • Dist Voltage: 600 VAC
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 80 A
  • Full Load Amp Minimum: Not applicable
  • Enclosure: Thermoplastic
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Copper/aluminum
  • Amperage Maximum: 80 A
  • Amperage Minimum: Not applicable
  • Nema Rating: Not specified
  • Switch Style: Toggle
  • Wire Size: 14 AWG to 2 AWG
  • Certification: UL, CSA
  • Circuit Breaker Mounting Style: Panel
  • Terminal Connection: Lug
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 1-phase
  • Standards: UL 489, CSA C22.2
  • Compatible Frames: 100 A frame
  • Installation Type: Fixed
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: 100 A
  • Current Rating: 80 A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not applicable
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 40°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 78211321992
  • GTIN: 00782113219929
