Cutler Hammer D15CR40A1B is a molded case circuit breaker designed for overcurrent protection in industrial power distribution systems. It is rated for 40 amps at 600 volts AC, providing reliable interruption of fault currents. The breaker features a compact 3.3-inch depth, 2.96-inch height, and 1.8-inch width, weighing 2.96 lb, with a robust thermoplastic housing. It complies with UL 489 and CSA C22.2 standards for safety and performance. This unit is typically used in panelboards, switchboards, and motor control centers for branch circuit protection.

Key Features & Specifications
  • Type: Molded case circuit breaker, thermal-magnetic trip, thermoplastic housing
  • Voltage Rating: 600 V AC
  • Current Rating: 40 A
  • Dimensions: 3.3 in x 2.96 in x 1.8 in (Length/Depth x Height x Width)
  • Weight: 2.96 lb
  • Standards: UL 489, CSA C22.2
  • Applications: Panelboards, switchboards, motor control centers
  • Breaker Type: Molded case
  • Trip Type: Thermal-magnetic
  • Frame Size: D15
  • Poles: 1
  • Phase: 1
  • Frequency Rating: 50/60 Hz
  • Circuit Breaker Mounting Style: Plug-in
  • Terminal Connection: Line and load lugs
  • AIC Rating: 10 kA at 600 V AC
  • Protection: Overcurrent and short-circuit
  • Functions: Circuit isolation and protection
  • Installation Type: Fixed
  • Item QTY: 1
  • Operating Temperature Maximum Celsius: 40 °C


Product Identification
  • UPC: 78211393655
  • GTIN: 00782113936550
