Thomas & Betts CPLG34 - Compression Lug 3/8" Stud #14-#4 AWG
Thomas & Betts CPLG34 - Compression Lug 3/8" Stud #14-#4 AWG

Thomas & Betts CPLG34 - Compression Lug 3/8" Stud #14-#4 AWG

Robroy
Price
Save $-6.45
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Thomas & Betts CPLG34 is a 3/8-inch compression lug designed for terminating copper conductors in industrial electrical applications. It is rated for 600V and accommodates a wire range of #14 AWG to #4 AWG, with a maximum current capacity determined by the connected conductor. Constructed from high-conductivity copper with a tin-plated finish for corrosion resistance, this lug features a single-hole, standard barrel design with a 3/8-inch stud hole and a 0.18 lb weight. It complies with UL 486A-486B and CSA C22.2 No. 65 standards, ensuring reliable performance in panel building, switchgear, and motor control center installations.

Key Features & Specifications
  • Type: Compression Lug, Copper, Tin-Plated, Standard Barrel
  • Voltage Rating: 600V
  • Current Rating: Dependent on conductor size (up to 85A for #4 AWG)
  • Dimensions: 3/8-inch stud hole, 1.50-inch length, 0.50-inch barrel ID
  • Standards: UL 486A-486B, CSA C22.2 No. 65
  • Applications: Panel building, switchgear, motor control centers, industrial power distribution
  • Wire Size: #14 AWG to #4 AWG
  • Metal Type: Copper, Tin-Plated
  • Mounting: Single Hole, 3/8-inch Stud
  • Connection: Compression
  • Barrels: Standard
  • Weight: 0.18 lb


Product Identification
  • UPC: 784011001323
  • GTIN: 00784011001323
