Cutler Hammer CH240EPD - 2-Pole 40A Circuit Breaker (10kA AIC)
Cutler Hammer CH240EPD - 2-Pole 40A Circuit Breaker (10kA AIC)
Cutler Hammer CH240EPD - 2-Pole 40A Circuit Breaker (10kA AIC)
Cutler Hammer CH240EPD - 2-Pole 40A Circuit Breaker (10kA AIC)

Cutler Hammer CH240EPD - 2-Pole 40A Circuit Breaker (10kA AIC)

Cutler Hammer
Price
Save $1,087.61
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer CH240EPD is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 40A current rating and a 240V AC voltage rating, housed in a compact plug-in configuration measuring 6 x 2.2 x 2.2 inches and weighing 1 lb. The breaker is UL 489 certified and employs a thermal-magnetic trip mechanism with both long-time and instantaneous functions for coordinated protection, capable of interrupting up to 10kA at 240V. Its construction supports a wide operating temperature range from -25 to 70 °C and accommodates copper or aluminum conductors from #14 to 6 AWG, making it suitable for panelboards, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Plug-In Connection
  • Voltage Rating: 240V AC
  • Current Rating: 40A
  • Dimensions: 6 in x 2.2 in x 2.2 in (Length/Depth x Height x Width)
  • Weight: 1 lb
  • Standards: UL 489
  • Applications: Panelboards, Switchboards, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Wire Size: #14 to 6 AWG Cu/Al
  • Certification: UL 489
  • Family: CH Series
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782113912974
  • GTIN: 00782113912974
