Siemens CED63B080 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a thermal-magnetic trip unit with long-time and instantaneous (LI) protection functions, rated for 80A at 600V AC with an interrupting capacity of 200kA at 480V. The breaker is constructed in a compact ED frame with a three-pole, bolt-on connection design suitable for copper or aluminum conductors from AWG 10 to 1/0. It complies with UL and IEC standards for safety and performance, operating reliably within a temperature range of -25 to 70 °C (-13 to 158 °F), making it suitable for panelboards, switchboards, and industrial control panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 80A
  • Frame Size: ED Frame
  • Poles: 3
  • Phase: 3
  • AIC Rating: 200kA at 480V
  • Protection Functions: LI (Long-Time and Instantaneous)
  • Connection: Bolt-On
  • Wire Size: AWG 10 to AWG 1/0, CU/AL
  • Certification: UL, IEC
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Weight: 5.69 lb
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643210738
  • GTIN: 00783643210738
