Cutler Hammer CCV2225 is a molded case circuit breaker designed for providing reliable overcurrent protection in single-phase commercial and tenant main applications. It features a 225A current rating and a 240V AC voltage rating, housed within a compact, durable frame measuring 8" x 5.5" x 4.5" and weighing 2.5 lb. This thermal-magnetic breaker is UL 489 certified and provides 10kA interrupting capacity at 240V, utilizing both long-time and instantaneous trip functions for comprehensive protection. Its two-pole, feed-thru configuration accommodates conductor sizes from 2/0 AWG to 300 kcmil for aluminum or copper, making it suitable for main disconnect and distribution panel protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker (CCV Type), Thermal-Magnetic Protection
  • Voltage Rating: 240V AC
  • Current Rating: 225A
  • Dimensions: 8 in (L) x 5.5 in (H) x 4.5 in (W)
  • Standards: UL 489 Certified
  • Applications: Tenant Main, Commercial Distribution
  • Switch Type: Circuit Breaker
  • Configuration: Feed-Thru
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Wire Size: 2/0 AWG to 300 kcmil, Al/Cu
  • Weight: 2.5 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786685368641
  • GTIN: 00786685368641
