Cutler Hammer CCV2125 - Molded Case Circuit Breaker 125A 2-Pole
Cutler Hammer CCV2125 - Molded Case Circuit Breaker 125A 2-Pole
Cutler Hammer CCV2125 - Molded Case Circuit Breaker 125A 2-Pole
Cutler Hammer CCV2125 - Molded Case Circuit Breaker 125A 2-Pole

Cutler Hammer CCV2125 - Molded Case Circuit Breaker 125A 2-Pole

Cutler Hammer
Price
Save $1,032.73
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler Hammer CCV2125 is a molded case circuit breaker designed to provide reliable overcurrent protection for single-phase, 240VAC electrical systems. It features a 125A current rating and a 10kA interrupting capacity at 240V, utilizing a thermal-magnetic trip mechanism for both long-time delay and instantaneous short-circuit protection. The compact, two-pole device with feed-thru connection measures 7.7" x 5.4" x 4.5" and is constructed for durability, weighing 2.9 lb. It is UL 489 listed and is commonly applied in tenant main and feeder circuit applications within commercial and industrial distribution panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker (CCV), Thermal Magnetic Protection
  • Voltage Rating: 240V AC
  • Current Rating: 125A
  • Dimensions: 7.7 in (L) x 5.4 in (H) x 4.5 in (W)
  • Standards: UL 489
  • Applications: Tenant Main, Feeder Protection
  • Switch Type: Circuit Breaker
  • Configuration: 2-Pole
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI) Trip
  • Weight: 2.9 lb
  • Certification: UL 489


Product Identification
  • UPC: 786685368399
  • GTIN: 00786685368399
