Cutler Hammer CC3225 - Molded Case Circuit Breaker 225A 3P (10kA AIC)
Cutler Hammer CC3225 - Molded Case Circuit Breaker 225A 3P (10kA AIC)
Cutler Hammer CC3225 - Molded Case Circuit Breaker 225A 3P (10kA AIC)
Cutler Hammer CC3225 - Molded Case Circuit Breaker 225A 3P (10kA AIC)

Cutler Hammer CC3225 - Molded Case Circuit Breaker 225A 3P (10kA AIC)

Cutler Hammer
Price
Save $1,401.26
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer CC3225 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power distribution systems. It features a 225A current rating and a 240V AC voltage rating, housed within a compact, durable frame measuring 7.75" x 5.25" x 5.75" (L x H x W) and weighing 4.2 lb. The breaker is UL 489 certified and utilizes a thermal-magnetic trip mechanism with long-time and instantaneous (LI) functions to ensure protection against both overloads and short circuits with an interrupting capacity of 10kA at 240V. Its feed-thru connection and compatibility with 2/0 AWG to 300 KCMIL aluminum or copper conductors make it suitable for main feeder and branch circuit protection in commercial and industrial panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection with Long-Time and Instantaneous (LI) Trip Functions
  • Voltage Rating: 240V AC
  • Current Rating: 225A
  • Dimensions: 7.75 in (Length/Depth) x 5.25 in (Height) x 5.75 in (Width)
  • Standards: Certified to UL 489
  • Applications: Main Feeder and Branch Circuit Protection in Industrial/Commercial Power Distribution
  • Phase: 3
  • AIC Rating: 10kA @ 240V
  • Connection: Feed-Thru
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous)
  • Wire Size: 2/0 AWG - 300 KCMIL (Aluminum/Copper)
  • Certification: UL 489
  • Weight: 4.2 lb
  • Family: CC Series
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782113266657
  • GTIN: 00782113266657
