Cutler Hammer CC3100 - Molded Case Circuit Breaker 100A 3P (10kA AIC)
Cutler Hammer CC3100 - Molded Case Circuit Breaker 100A 3P (10kA AIC)
Cutler Hammer CC3100 - Molded Case Circuit Breaker 100A 3P (10kA AIC)
Cutler Hammer CC3100 - Molded Case Circuit Breaker 100A 3P (10kA AIC)

Cutler Hammer CC3100 - Molded Case Circuit Breaker 100A 3P (10kA AIC)

Cutler Hammer
Price
Save $560.98
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Cutler Hammer CC3100 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power distribution systems. It features a 100A current rating and a 240V AC voltage rating, housed within a compact, durable frame measuring 8" x 5.5" x 4.5" (L x H x W) and weighing 3 lb. The breaker is UL 489 certified and employs a thermal-magnetic trip unit with long-time and instantaneous (LI) functions to ensure protection against both overloads and short circuits with an interrupting capacity of 10kA at 240V. Its feed-thru connection and compatibility with 4-4/0 AWG aluminum or copper conductors make it suitable for a range of commercial and industrial panelboard applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 240V AC
  • Current Rating: 100A
  • Dimensions: 8 in (L) x 5.5 in (H) x 4.5 in (W)
  • Standards: UL 489
  • Applications: Industrial Power Distribution, Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 3
  • Poles: 3
  • AIC Rating: 10kA @ 240V
  • Connection: Feed-Thru
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: CC Series
  • Trip Type: Thermal-Magnetic
  • Wire Size: 4-4/0 AWG (Aluminum/Copper)
  • Certification: UL 489
  • Weight: 3 lb


Product Identification
  • UPC: 782113386553
  • GTIN: 00782113386553
