Cutler Hammer C400T6 - Class T Fuse 600V 400A (Industrial Overcurrent)
Cutler Hammer C400T6 - Class T Fuse 600V 400A (Industrial Overcurrent)

Cutler Hammer C400T6 - Class T Fuse 600V 400A (Industrial Overcurrent)

Cutler Hammer
Price
Save $43.93
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer C400T6 is a heavy-duty industrial fuse designed for overcurrent protection in electrical distribution systems. This 600-volt AC-rated fuse handles a continuous current of 400 amperes, providing reliable short-circuit and overload protection for branch circuits and main feeders. Constructed with a compact 5.7-inch depth, 3.8-inch height, and 4-inch width, the C400T6 weighs 1 lb and features a non-renewable, one-time operation design with a Class T rejection-style body for secure mounting. It complies with UL and CSA standards for industrial safety and performance. Typical applications include protecting motor control centers, panelboards, and switchboards in manufacturing plants, commercial buildings, and utility installations.

Key Features & Specifications
  • Type: Class T, non-renewable, one-time fuse with rejection-style body
  • Voltage Rating: 600 V AC
  • Current Rating: 400 A
  • Dimensions: 5.7 in x 3.8 in x 4 in (Length/Depth x Height x Width)
  • Standards: UL Listed, CSA Certified
  • Applications: Overcurrent protection for motor control centers, panelboards, switchboards, and feeder circuits
  • Weight: 1 lb
  • Amperage: 400 A
  • Fuse Class: Class T
  • Mounting: Rejection-style clip
  • Frequency Rating: 50/60 Hz
  • Interrupting Rating: 200 kA RMS Symmetrical
  • Terminal Connection: Ferrule or blade
  • Installation Type: Bolt-on or clip-in
  • Metal Type: Copper alloy
  • Insulation Temperature: 90°C
  • Horse Power: Not applicable (fuse only)
  • Certification: UL 248-15, CSA C22.2 No. 248.15


Product Identification
  • UPC: 78211411476
  • GTIN: 00782114114766
