Cutler Hammer BWH2100 - 100A 2-Pole Molded Case Breaker 240V
Cutler Hammer BWH2100 - 100A 2-Pole Molded Case Breaker 240V

Cutler Hammer BWH2100 - 100A 2-Pole Molded Case Breaker 240V

Cutler Hammer
Price
Save $1,999.60
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer BWH2100 is a 2-pole molded case circuit breaker designed for thermal magnetic overcurrent protection in 1-phase industrial applications. It is rated for 100A at 240V with a 25kA interrupting capacity at 240V, utilizing LI (Long-Time and Instantaneous) trip functions. The unit features a bolt-on connection, measures 6.25 in x 5.25 in x 5.25 in (Length/Depth x Height x Width), weighs 2.75 lb, and accepts wire sizes from 2 AWG (Copper) to 300 kcmil (Aluminium). It is UL 489 listed and meets Federal Specifications Classification W-C375, with an operating temperature range of -13°F to 158°F (-25°C to 70°C). This breaker is suitable for panelboard and switchboard installations requiring reliable branch circuit protection.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic
  • Voltage Rating: 240V
  • Current Rating: 100A
  • Poles: 2
  • Phase: 1
  • AIC Rating: 25kA@240V
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Wire Size: 2 AWG (Copper) to 300 kcmil (Aluminium)
  • Dimensions: 6.25 in x 5.25 in x 5.25 in (Length/Depth x Height x Width)
  • Weight: 2.75 lb
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Certification: UL 489, Federal Specifications Classification W-C375
  • Family: BWH Series
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782116061105
  • GTIN: 00782116061105
