Cutler Hammer BRX2100 - 2-Pole 100A Thermal-Magnetic Breaker
Cutler Hammer BRX2100 - 2-Pole 100A Thermal-Magnetic Breaker

Cutler Hammer BRX2100 - 2-Pole 100A Thermal-Magnetic Breaker

Cutler Hammer
Price
Save $1,598.04
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer BRX2100 is a molded case circuit breaker designed for providing reliable overcurrent protection in single-phase electrical systems. It features a 100A current rating and a 240V AC voltage rating, housed within a compact plug-in configuration measuring 2.48" x 2.938" x 2" and weighing 0.76 lb. The breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous protection, is UL listed, and complies with federal specification W-C375. It is engineered for industrial and commercial applications, offering a 65kA interrupting capacity at 240V and an operational temperature range of -25°C to 70°C (-13°F to 158°F).

Key Features & Specifications
  • Type: BRX Series Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 240V AC
  • Current Rating: 100A
  • Dimensions: 2.48 in (D) x 2.938 in (H) x 2 in (W)
  • Standards: UL Listed (File E7819), Federal Spec W-C375
  • Applications: Industrial & Commercial Electrical Distribution
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • Amperage: 100A
  • AIC Rating: 65kA @ 240V
  • Connection: Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Wire Size: AWG 14 to AWG 2/0
  • Certification: UL Listed
  • Family: BR Series
  • Country of Origin: Dominican Republic
  • Weight: 0.76 lb


Product Identification
  • UPC: 786685926803
  • GTIN: 00786685926803
