Cutler-Hammer BQC2252115 - 2-Pole 25A Circuit Breaker (10kA AIC)
Cutler-Hammer BQC2252115 - 2-Pole 25A Circuit Breaker (10kA AIC)

Cutler-Hammer BQC2252115 - 2-Pole 25A Circuit Breaker (10kA AIC)

Cutler Hammer
Price
Save $353.90
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
The Cutler-Hammer BQC2252115 is a molded case circuit breaker designed to provide reliable overcurrent protection for industrial and commercial electrical systems. It features a 25A current rating and a 240V AC voltage rating, housed within a compact 3" x 3" x 2" plug-in unit with a lug terminal connection. This thermal-magnetic breaker offers both long-time and instantaneous (LI) trip functions, is HACR rated and UL 489 listed, and provides a 10kA interrupting capacity at 240V for robust short-circuit protection. Its design supports wiring from AWG 14 to AWG 4 (copper or aluminum), making it suitable for a range of branch circuit applications in panelboards and switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Plug-In Connection
  • Voltage Rating: 240V AC
  • Current Rating: 25A
  • Dimensions: 3 in (L) x 3 in (H) x 2 in (W)
  • Standards: UL Listed (UL 489), HACR Rated, Federal Spec W-C390
  • Applications: Industrial & Commercial Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Plug-In, Lug Terminal
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time & Instantaneous Trip (LI)
  • Wire Size: AWG 14 to AWG 4, Cu/Al
  • Certification: UL 489
  • Terminal Connection: Lug
  • Family: BQ Series
  • Country of Origin: Dominican Republic
  • Weight: 0.5 lb


Product Identification
  • UPC: 786676371766
  • GTIN: 00786676371766
