Siemens BQ2B09000S01 - Molded Case 90A 240V Shunt Trip
Siemens BQ2B09000S01 - Molded Case 90A 240V Shunt Trip

Siemens BQ2B09000S01 - Molded Case 90A 240V Shunt Trip

Siemens
Price
Save $432.43
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQ2B09000S01 is a 2-pole molded case circuit breaker designed for thermal magnetic protection in Siemens panelboards. This 90A, 240V unit provides long time and instantaneous trip functions with a 10kA@240V interrupting capacity. The breaker measures 5.906 x 3.937 x 2.756 inches, weighs 0.904 lb, and features bolt-on connection with lug terminals accepting 8 AWG to 2 AWG (Al) or 4 AWG (Cu) wire. It is UL Listed, CSA certified, and HACR rated for compliance with industry standards. This shunt trip breaker, complete with a non-interchangeable 120V shunt trip, is suitable for 1-phase industrial applications within a temperature range of -13 to 158 °F (-25 to 70 °C).

Key Features & Specifications
  • Type: Molded Case, BQ Series, Thermal Magnetic
  • Voltage Rating: 240V
  • Current Rating: 90A
  • Dimensions: 5.906 x 3.937 x 2.756 inch
  • Standards: UL Listed, CSA, HACR
  • Applications: Siemens Panelboards, 1-Phase Industrial
  • Switch Type: Shunt Trip
  • Configuration: 2-Pole
  • Coil Voltage Maximum: 120V
  • Temp Rating: -13 to 158 °F (-25 to 70 °C)
  • Shipping Dimensions: 5.906 x 3.937 x 2.756 inch
  • Phase: 1
  • Voltage: 240V
  • Amperage: 90A
  • AIC rating: 10kA@240V
  • Connection: Bolt-on
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: 125A/BQ
  • Trip Type: Non-interchangeable Shunt Trip
  • Panel Type: Siemens Panelboards
  • Breaker Type: Shunt Trip
  • Control Voltage Minimum: 120V
  • Control Voltage Maximum: 120V
  • MCM Size: Min. Wire Size 8 AWG, Max. Wire Size 2 AWG (Al), 4 AWG (Cu)
  • Metal Type: Molded Case
  • Panel Style: Siemens
  • Bus Type: Bolt-on
  • Fuse Class: N/A
  • Insulation Temperature: N/A
  • Inductance: N/A
  • Impedance: N/A
  • Barrels: N/A
  • Class Rating: N/A
  • Diameter: N/A
  • Velocity: N/A
  • Clip Center: N/A
  • Clas: N/A
  • Mounting: Bolt-on
  • Hz: 60
  • Coil Material: N/A
  • Horse Power: N/A
  • Aux Contacts: N/A
  • CPT: N/A
  • Full Load Amps: N/A
  • Dist Voltage: N/A
  • Bucket Size: N/A
  • Bucket Style: N/A
  • Bucket Type: N/A
  • Full Load Amp Maximum: N/A
  • Full Load Amp Minimum: N/A
  • Enclosure: N/A
  • Relay Style: N/A
  • Coil Voltage Minimum: 120V
  • Wire: N/A
  • Amperage Maximum: 90A
  • Amperage Minimum: N/A
  • Nema Rating: N/A
  • Switch Style: Shunt Trip
  • Wire Size: 8 AWG to 2 AWG (Al), 4 AWG (Cu)
  • Certification: UL, CSA, HACR
  • Circuit Breaker Mounting Style: Bolt-on
  • Terminal Connection: Lug
  • Frequency Rating: 60 Hz
  • Phase Connection: 1-Phase
  • Standards: UL Listed, CSA, HACR
  • Compatible Frames: BQ Series
  • Installation Type: Panelboard
  • Item QTY: 1
  • Nema Starter Size: N/A
  • Breaker Frame: 125A/BQ
  • Current Rating: 90A
  • Reverse Standoff Voltage: N/A
  • Watts: N/A
  • Peak Pulse Current: N/A
  • Breakdown Voltage (MIN VBR@IT ) (V): N/A
  • Breakdown Voltage (VBR@IT) (V): N/A
  • Polarity: N/A
  • Operating Temperature Maximum Celsius: 70 °C
  • Max Clamp Voltage: N/A
  • On-State Current: N/A


Product Identification
  • UPC: 783643237797
  • GTIN: 00783643237797
