Siemens BQ2B07000S01 - Molded Case 70A 2-Pole Shunt Trip
Siemens BQ2B07000S01 - Molded Case 70A 2-Pole Shunt Trip

Siemens BQ2B07000S01 - Molded Case 70A 2-Pole Shunt Trip

Siemens
Price
Save $430.70
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Siemens BQ2B07000S01 is a 2-pole molded case circuit breaker designed for thermal magnetic overcurrent protection in Siemens panelboards. It is rated for 70A at 120/240V AC with a 10kA interrupting capacity at 240V, and it includes a non-interchangeable 120V shunt trip for remote tripping. The unit measures 5.906 x 3.937 x 2.756 inches, weighs 1.213 lb, and features a bolt-on connection with lug terminals accepting 8 AWG to 2 AWG aluminum or 4 AWG copper wire. It is UL Listed, HACR Rated, and CSA certified for use in 1-phase systems within an ambient temperature range of -13 to 158 °F (-25 to 70 °C). This BQ Series breaker is suited for industrial and commercial applications requiring reliable branch circuit protection with shunt trip capability.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic, Shunt Trip
  • Voltage Rating: 120/240V
  • Current Rating: 70A
  • Dimensions: 5.906 x 3.937 x 2.756 inch
  • Standards: HACR Rated, UL Listed, CSA Certified
  • Applications: Siemens Panelboards, Industrial Branch Circuits
  • Poles: 2
  • Connection: Bolt-on
  • AIC rating: 10kA@240V
  • Frame Size: 125A/BQ
  • Trip Type: Long Time and Instantaneous Trip
  • Terminal Connection: Lug
  • MCM Size: Min. Wire Size 8 AWG Max. Wire Size 2 AWG (Al), 4 AWG (Cu)
  • Phase: 1
  • Temp Rating: -13 to 158 °F (-25 to 70 °C)
  • Breaker Type: Shunt Trip
  • Additional Info: complete with non-interchangeable 120V shunt trip


Product Identification
  • UPC: 783643237773
  • GTIN: 00783643237773
