Siemens BG230 - Molded Case Circuit Breaker 30A 2-Pole
Siemens BG230 - Molded Case Circuit Breaker 30A 2-Pole

Siemens BG230 - Molded Case Circuit Breaker 30A 2-Pole

Siemens
Price
Save $238.21
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BG230 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features a 30A current rating and a 120V AC voltage rating, housed within a compact, bolt-on configuration measuring 3.937 x 2.756 x 2.756 inches (100 x 70 x 70 mm) and weighing 0.992 lb. The breaker utilizes a thermal-magnetic trip unit combining long-time and instantaneous trip functions to ensure protection coordination, and it is rated for an interrupting capacity of 10kA at 120V. Constructed for durability, it operates effectively across a temperature range of -25 to 70 °C and is compliant with relevant industry standards for safety and performance in commercial and light industrial panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 120V AC
  • Current Rating: 30A
  • Dimensions: 3.937 x 2.756 x 2.756 inch (100 x 70 x 70 mm)
  • Standards: Compliant with applicable UL and IEC standards
  • Applications: Commercial and light industrial panelboards, load centers
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25 to 70 °C
  • Phase: 1
  • AIC Rating: 10kA @ 120V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: BG Series
  • Trip Type: Thermal-Magnetic
  • Breaker Type: Molded Case
  • Family: BL Series
  • Country of Origin: Mexico
  • Weight: 0.992 lb


Product Identification
  • UPC: 783643271203
  • GTIN: 00783643271203
