Siemens BE115H is a molded case circuit breaker designed for ground fault equipment protection in single-phase 120V AC systems. It provides a 15A current rating with a 22kA interrupting capacity at 120V, utilizing a thermal magnetic trip mechanism for both long-time and instantaneous overcurrent protection. The compact, bolt-on unit measures 0.787" x 3.937" x 4.724" (20mm x 100mm x 120mm) and weighs 0.507 lb, featuring a lug terminal connection compatible with wire sizes from 12 AWG (Al) or 14 AWG (Cu) minimum to 10 AWG maximum. It is fully certified to UL, CSA, HACR, and NOM standards and operates reliably within a temperature range of -25°C to 70°C (-13°F to 158°F). This breaker is engineered for integration into Siemens P1 panelboards, offering reliable protection for commercial and light industrial branch circuits.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, BLEH Type, Ground Fault Equipment Protection
  • Voltage Rating: 120V AC
  • Current Rating: 15A
  • Frame Size: 60A/BLEH
  • Poles: 1
  • Phase: 1
  • AIC Rating: 22kA @ 120V
  • Protection: Thermal Magnetic
  • Trip Functions: Long Time and Instantaneous Trip
  • Connection: Bolt-on
  • Terminal Connection: Lug
  • MCM Wire Size: Min. 12 AWG (Al) / 14 AWG (Cu), Max. 10 AWG
  • Panel Type: Siemens P1 Panelboards
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Standards & Certification: UL Listed, CSA Certified, HACR Rated, NOM Certified
  • Dimensions: 0.787" x 3.937" x 4.724" (20mm x 100mm x 120mm)
  • Weight: 0.507 lb
  • Family: BL Series
  • Country of Origin: Philippines


Product Identification
  • UPC: 783643266124
  • GTIN: 00783643266124
