Siemens B23500S01 - Molded Case Circuit Breaker 35A 2-Pole
Siemens B23500S01 - Molded Case Circuit Breaker 35A 2-Pole

Siemens B23500S01 - Molded Case Circuit Breaker 35A 2-Pole

Siemens
Price
Save $336.27
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Siemens B23500S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 35A current rating and a 240V AC voltage rating, housed within a compact 125A/BL frame with a two-pole, bolt-on lug connection for secure installation. The breaker is constructed with thermal-magnetic trip technology for both long-time delay and instantaneous response, and it operates reliably across a temperature range of -25°C to 70°C (-13°F to 158°F). It complies with key industry standards including UL listing, CSA certification, HACR rating, and NOM certification, ensuring safety and interoperability. This shunt trip breaker, complete with a 120V shunt trip coil, is typically applied in Siemens P1 panelboards for feeder and branch circuit protection in single-phase applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, BL Series, Thermal Magnetic Protection with Shunt Trip
  • Voltage Rating: 240V AC
  • Current Rating: 35A
  • Frame Size: 125A/BL
  • Poles: 2
  • Connection: Bolt-on, Lug Terminal
  • AIC Rating: 10kA @ 240V
  • Phase: 1
  • Protection Functions: Long Time and Instantaneous Trip
  • Breaker Type: Shunt Trip (includes 120V shunt trip coil)
  • Panel Type: Compatible with Siemens P1 Panelboards
  • Standards & Certification: UL Listed, CSA Certified, HACR Rated, NOM Certified
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Wire Size Range (MCM): Minimum 12 AWG (Al) / 14 AWG (Cu), Maximum 6 AWG
  • Weight: 1.08 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643089303
  • GTIN: 00783643089303
