Siemens B220HH00S01 - Molded Case 20A 2-Pole Breaker
Siemens B220HH00S01 - Molded Case 20A 2-Pole Breaker

Siemens B220HH00S01 - Molded Case 20A 2-Pole Breaker

Siemens
Price
Save $1,061.99
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Siemens B220HH00S01 is a 2-pole, 20A molded case circuit breaker from the BL Series, designed for overcurrent protection via a thermal magnetic trip mechanism with long time and instantaneous trip functions. It is rated for 120/240V AC with a high interrupting capacity of 65kA at 240V and features a shunt trip for remote disconnection. The breaker measures 5.906 x 3.937 x 3.937 inches, weighs 2.205 lb, and uses a bolt-on connection for secure mounting in Siemens P1 panelboards. It is CSA Certified, HACR Rated, NOM Certified, and UL Listed, with an operating temperature range of -13 to 158 °F (-25 to 70 °C). This single-phase unit is suited for commercial and industrial applications requiring reliable branch circuit protection.

Key Features & Specifications
  • Type: HBL
  • Current Rating: 20A
  • Voltage Rating: 120/240V
  • Poles: 2
  • Phase: 1
  • Interrupt Rating: 65kA@240V
  • Breaker Type: Shunt Trip
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Connection: Bolt-On
  • Panel Type: Siemens P1 Panelboards
  • Dimensions: 5.906 x 3.937 x 3.937 inch
  • Weight: 2.205 lb
  • Temp Rating: -13 to 158 °F (-25 to 70 °C)
  • Family: BL Series
  • Standards: CSA Certified, HACR Rated, NOM Certified, UL Listed
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643089471
  • GTIN: 00783643089471
