Siemens B2110H - 110A 2-Pole Bolt-On (22kA AIC)
Siemens B2110H - 110A 2-Pole Bolt-On (22kA AIC)

Siemens B2110H - 110A 2-Pole Bolt-On (22kA AIC)

Siemens
Price
Save $2,046.42
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens B2110H Circuit Breaker - 110A 2-Pole Bolt-On (22kA AIC) for P1 Panelboards The Siemens B2110H is a 2-pole, 110A molded case circuit breaker from the BL Series, designed for thermal magnetic overcurrent protection in residential and light commercial applications. It operates at 120/240VAC with a high interrupting capacity of 22kA at 120/240VAC, ensuring robust fault current handling. This bolt-on unit measures 3 in x 2 in x 2 in and weighs 0.75 lb, featuring a compact construction for direct installation into Siemens P1 panelboards. It is CSA Certified, HACR Rated, NOM Certified, and UL Listed, meeting rigorous safety and performance standards for single-phase systems. Typical applications include branch circuit protection in panelboards, lighting panels, and distribution boards where reliable thermal magnetic trip action is required.

Key Features & Specifications
  • Type: Molded case, thermal magnetic, bolt-on
  • Voltage Rating: 120/240VAC
  • Current Rating: 110A
  • Dimensions: 3 in x 2 in x 2 in
  • Weight: 0.75 lb
  • Standards: CSA Certified, HACR Rated, NOM Certified, UL Listed
  • Applications: Branch circuit protection in Siemens P1 panelboards
  • Circuit Breaker Mounting Style: Panelboard
  • Panel Type: Siemens P1 Panelboards
  • Poles: 2
  • Connection: Bolt-on
  • Protection: Thermal Magnetic
  • AIC rating: 22kA at 120/240VAC
  • Phase: 1
  • Family: BL Series
  • Type: BLH
  • Country of Origin: Mexico
  • Compatible Frames: P1 Panelboards


Product Identification
  • UPC: 783643619227
  • GTIN: 00783643619227
