Cutler-Hammer ATQR8/10 - Class CC Fuse 8A 600V (200kA AIC)
Cutler-Hammer ATQR8/10 - Class CC Fuse 8A 600V (200kA AIC)

Cutler-Hammer ATQR8/10 - Class CC Fuse 8A 600V (200kA AIC)

Cutler Hammer
Price
Save $73.70
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler-Hammer ATQR8/10 is a Class CC low-voltage current-limiting fuse designed to provide superior short-circuit protection for control circuits and transformers. It features a 600V AC voltage rating and an 8A current rating, with a compact single-barrel construction measuring 1-1/2 inches in length and 0.41 inches in diameter. This fuse is UL/CSA certified and offers a high 200kA interrupting rating at 600V AC, ensuring reliable performance under severe fault conditions. Typical applications include industrial control panels, motor control centers, and transformer protection circuits where space is limited and high fault current protection is required.

Key Features & Specifications
  • Type: Class CC, current-limiting, low-voltage fuse, single barrel
  • Voltage Rating: 600V AC
  • Current Rating: 8A
  • Dimensions: 1-1/2 in length, 0.41 in diameter
  • Standards: UL/CSA Certified
  • Applications: Control circuits, transformer protection, motor control centers
  • AIC rating: 200kA @ 600V AC
  • Class Rating: CC
  • Barrels: 1
  • Weight: 5 lb
  • Family: Amp-Trap 2000
  • Country of Origin: Mexico


Product Identification
  • UPC: 782001906368
  • GTIN: 00782001906368
