Mersen ATQR5-6/10 - Class CC Fuse 5A 600V (200kA AIC)

Mersen ATQR5-6/10 is a low-voltage current-limiting fuse from the Amp-Trap 2000 family, designed for circuit protection in industrial electrical systems. Rated for 600V AC/DC with a 5A current capacity, it features a compact 1-1/2-inch cylindrical design (0.41-inch diameter) and UL/CSA-certified construction. The Class CC fuse delivers 200kA interrupting capacity at rated voltage, meeting stringent protection requirements for motor control centers, transformers, and power distribution equipment.

Key Features & Specifications

• Type: ATQR current-limiting fuse, single-barrel design
• Voltage Rating: 600V AC/DC
• Current Rating: 5A
• Dimensions: 1-1/2 in length, 0.41 in diameter
• Standards: UL/CSA certified
• Applications: Motor controls, transformers, power distribution
• Class Rating: CC
• AIC rating: 200kA@600V
• Weight: 0.02 lb
• Country of Origin: Mexico

Product Identification

• UPC: 782001906597
• GTIN: 00782001906597
