Mersen ATQR3-1/2 - Class CC Fuse 3A 600V (200kA AIC Rating)

Mersen ATQR3-1/2 is a Class CC low-voltage current-limiting fuse designed for circuit protection in industrial electrical systems. It features a 600V AC voltage rating and 3A current rating with 200kA interrupting capacity at 600V for reliable short-circuit protection. The fuse construction utilizes a single-barrel design measuring 1-1/2 inches in length and 0.41 inches in diameter, weighing 0.02 lb for compact installation. Certified to UL/CSA standards, this Amp-Trap 2000 series fuse meets rigorous safety requirements for industrial applications including control circuits, transformers, and motor branch circuits where Class CC protection is specified.

Key Features & Specifications

• Type: Class CC current-limiting fuse, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 3A
• Dimensions: 1-1/2 inches length, 0.41 inches diameter
• Standards: UL/CSA certified
• Applications: Industrial control circuits, transformers, motor protection
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 0.02 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001906559
• GTIN: 00782001906559
