Mersen ATQR1/2 - Class CC Fuse 1A 600V (200kA AIC Rating)

Mersen ATQR1/2 is a current-limiting fuse designed for comprehensive circuit protection in industrial electrical systems. This Class CC fuse operates with a 1A current rating and 600V voltage rating, providing reliable overcurrent protection with a high 200kA interrupting rating at 600V. The fuse features a compact single-barrel construction measuring 1-1/2 inches in length with a 0.41-inch diameter and 5 lb weight, engineered for space-constrained applications. It carries UL/CSA certification and meets industry standards for safety and performance. Typical applications include protection of control circuits, transformers, and motor circuits in industrial facilities and commercial buildings.

Key Features & Specifications

• Type: Current-limiting Class CC fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL/CSA certified
• Applications: Industrial control circuits, transformers, motor protection
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 5 lb
• Certification: UL/CSA
• Family: Amp-Trap 2000
• Item Subcategory: Low Voltage Fuse
• Country of Origin: Mexico

Product Identification

• UPC: 078200190633
• GTIN: 00782001906337
