Mersen ATQ3/10 - Low Voltage Fuse 3A 500V (10kA AIC Rating)

Mersen ATQ3/10 is a low voltage fuse designed for circuit protection in industrial applications. It provides reliable overcurrent protection with a 3A current rating and 500V voltage rating, featuring a compact midget class design measuring 1-1/2 inches in length with 0.41-inch diameter. The fuse meets CSA and UL certification standards and offers 10kA interrupting capacity at 500V for robust fault protection. Typical applications include motor control centers, panelboards, and industrial control circuits where space-efficient protection is required.

Key Features & Specifications

• Type: Low Voltage Fuse, Amp-Trap Family, ATQ Type
• Voltage Rating: 500V AC
• Current Rating: 3A
• Dimensions: 1-1/2 inch length
• Standards: CSA, UL Certified
• Applications: Industrial control circuits, motor protection, panelboards
• AIC rating: 10kA@500V
• Class Rating: Midget
• Barrels: 1
• Diameter: 0.41 inch
• Weight: 5 lb
• Country of Origin: Mexico

Product Identification

• UPC: 782001902643
• GTIN: 00782001902643
