Cutler Hammer ATQ1/4 - Current-Limiting Fuse 1A (10kA AIC, 500V)
Cutler Hammer ATQ1/4 - Current-Limiting Fuse 1A (10kA AIC, 500V)
Cutler Hammer ATQ1/4 - Current-Limiting Fuse 1A (10kA AIC, 500V)
Cutler Hammer ATQ1/4 - Current-Limiting Fuse 1A (10kA AIC, 500V)

Cutler Hammer ATQ1/4 - Current-Limiting Fuse 1A (10kA AIC, 500V)

Cutler Hammer
Price
Save $958.83
/
Title
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
The Cutler Hammer ATQ1/4 is a low voltage current-limiting fuse from the Amp-Trap family, designed to provide superior short-circuit protection for sensitive electrical components. It features a 1A current rating and a 500V AC voltage rating, with a high interrupting capacity of 10kA. The fuse is constructed as a single-barrel, midget-class device with a compact diameter of 0.41 inches and a length of 1-1/2 inches, weighing 0.01 lb for straightforward integration. It is certified to UL and CSA standards for reliable performance and safety compliance. This fuse is typically applied in industrial control circuits, motor branch circuits, and transformer protection where high fault current interruption is critical.

Key Features & Specifications
  • Type: ATQ, Amp-Trap current-limiting fuse, midget class, single barrel
  • Voltage Rating: 500V AC
  • Current Rating: 1A
  • Dimensions: 1-1/2 in length, 0.41 in diameter
  • Standards: UL, CSA
  • Applications: Industrial control circuits, motor branch circuits, transformer protection
  • AIC rating: 10kA@500V
  • Certification: CSA, UL
  • Class Rating: midget
  • Barrels: 1
  • Weight: 0.01 lb
  • Family: Amp-Trap
  • Item Subcategory: Low Voltage Fuse
  • Country of Origin: Mexico


Product Identification
  • UPC: 078200190274
  • GTIN: 00782001902742
