Mersen ATDR1/4 - Class CC Fuse 1A 600V (200kA AIC)

Mersen ATDR1/4 is a low voltage current-limiting fuse designed for protecting sensitive electrical components and control circuits from short-circuit conditions. It features a 600V AC voltage rating with a 1A current rating and 200kA interrupting capacity at 600V for reliable fault protection. The fuse construction utilizes a single-barrel design with 0.41-inch diameter and 1-1/2-inch length, weighing 0.02 lb for compact installation. Certified to UL/CSA standards with Class CC rating, this fuse meets rigorous safety requirements for industrial applications including motor control centers, industrial control panels, and power distribution systems where precise overcurrent protection is critical.

Key Features & Specifications

• Type: Current-limiting fuse, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL/CSA certified
• Applications: Motor control centers, industrial control panels, power distribution systems
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 0.02 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 78200190845
• GTIN: 00782001908454
