Mersen A70QS40-22F is a low voltage current-limiting fuse from the Amp-Trap family designed for comprehensive circuit protection in industrial power systems. It features a 40A current rating and 690V voltage rating with exceptional 200kA interrupting capacity at rated voltage. The fuse employs a single-barrel ferrule connection design with 22mm diameter and 2-1/4 inch length construction weighing 1 lb. It carries UL Recognized Component File E76491 and CSA certifications for reliable performance in demanding industrial environments including motor control centers, distribution panels, and power conversion equipment.

Key Features & Specifications
  • Type: Low Voltage Current-Limiting Fuse, Amp-Trap Family, Single Barrel Ferrule Connection
  • Voltage Rating: 690V AC
  • Current Rating: 40A
  • Dimensions: 22mm Diameter x 2-1/4 inch Length
  • Standards: UL Recognized Component File E76491, CSA Certified
  • Applications: Industrial Power Systems, Motor Control Centers, Distribution Panels
  • AIC rating: 200kA@690V
  • Connection: Ferrule
  • Barrels: 1
  • Weight: 1 lb
  • Certification: UL Recognized Component File E76491, CSA Certified


Product Identification
  • UPC: 78200114209
  • GTIN: 00782001142094
