Mersen A70QS10-22F - Low Voltage Fuse 10A 690V (200kA AIC Rating)

Mersen A70QS10-22F is a low voltage current-limiting fuse designed for comprehensive circuit protection in industrial power systems. It provides 10A current protection with a 690V voltage rating and features exceptional 200kA interrupting capacity at full voltage. The fuse employs a single-barrel ferrule connection design with a 22mm diameter construction for reliable performance. Certified to UL Recognized Component, CSA, and IEC 269-4 standards, this Amp-Trap family fuse is engineered for demanding applications including motor control centers, industrial control panels, and power distribution systems where high fault current protection is critical.

Key Features & Specifications

• Type: Low voltage current-limiting fuse, single barrel ferrule connection
• Voltage Rating: 690V AC
• Current Rating: 10A
• Dimensions: 22mm diameter
• Standards: UL Recognized Component, CSA Certified, IEC 269-4 Compliance
• Applications: Industrial power systems, motor control centers, distribution panels
• AIC rating: 200kA@690V
• Connection: Ferrule
• Barrels: 1
• Family: Amp-Trap
• Type: A70QS
• Weight: 1 lb

Product Identification

• UPC: 78200135883
• GTIN: 00782001358839
