Mersen A6D2.8R - Class RK1 Time-Delay Fuse 2.8A 600V
Mersen A6D2.8R - Class RK1 Time-Delay Fuse 2.8A 600V

Mersen A6D2.8R - Class RK1 Time-Delay Fuse 2.8A 600V

Mersen
Price
Save $94.23
/
Condition
  • Low stock - 10 items left
  • Backordered, shipping soon
Call for Price
Mersen A6D2.8R is a Class RK1 time-delay fuse engineered for overcurrent and short-circuit protection in industrial, commercial, and residential electrical systems. It is rated for 2.8A at 600V AC/DC, with a high interrupting capacity of 200,000A AC and 100,000A DC, and its time-delay characteristic accommodates high inrush currents typical of motors and transformers without nuisance tripping. The fuse measures 5 inches in length by 0.81 inches in diameter, weighs 0.14 lb, and features a fiberglass body with ferrule mounting for dimensional stability and a SmartSpot visual blown fuse indicator for easy status identification. It is UL Listed and CSA Certified, with a current-limiting design that reduces peak let-thru current during faults and provides arc flash mitigation. This fuse is suitable for protecting motor circuits, transformers, and general branch circuits in demanding environments.

Key Features & Specifications
  • Type: Class RK1 Time-Delay Fuse
  • Amperage Rating: 2.8A
  • Voltage Rating: 600V AC/DC
  • Poles: 1
  • Interrupting Rating: 200,000A AC, 100,000A DC
  • Series/Frame: A6D
  • Mounting Type: Ferrule
  • Response Time: Time-Delay
  • Protection Type: Arc Flash Mitigating
  • Dimensions: Length 5 inches X Diameter .81 inches
  • Weight: 0.14 lb
  • Physical Size: 13/16" x 5"
  • UL Listed
  • CSA Certified
  • UPC: 782001307875
