Cutler Hammer A6D1-1/8R - Class RK1 Fuse 1A 600V (200kA AIC)
Cutler Hammer A6D1-1/8R - Class RK1 Fuse 1A 600V (200kA AIC)
Cutler Hammer A6D1-1/8R - Class RK1 Fuse 1A 600V (200kA AIC)
Cutler Hammer A6D1-1/8R - Class RK1 Fuse 1A 600V (200kA AIC)

Cutler Hammer A6D1-1/8R - Class RK1 Fuse 1A 600V (200kA AIC)

Cutler Hammer
Price
Save $87.39
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler Hammer A6D1-1/8R is a Class RK1 low-voltage current-limiting fuse from the Amp-Trap 2000 family, engineered to provide superior short-circuit protection for electrical circuits and equipment. It features a 1A current rating and a 600V AC/DC voltage rating, with an impressive 200kA interrupting capacity at 600V to safely clear high-level faults. The fuse is constructed as a single-barrel unit with a 5-inch body length and 0.81-inch diameter, weighing 5.19 lb for robust industrial handling. This component is certified to UL 248-12 and CSA C22.2 No. 248.12 standards, ensuring compliance with North American safety requirements. Typical applications include the protection of motor controls, transformers, and feeders in industrial power distribution systems where high interrupting capacity and current limitation are critical.

Key Features & Specifications
  • Type: Class RK1, Amp-Trap 2000, Current-Limiting, Low-Voltage Fuse
  • Voltage Rating: 600V AC/DC
  • Current Rating: 1A
  • Dimensions: 5" Length, 0.81" Diameter
  • Weight: 5.19 lb
  • Standards: UL 248-12, CSA C22.2 No. 248.12
  • Applications: Motor Control, Transformer, and Feeder Protection
  • AIC rating: 200kA @ 600V
  • Barrels: 1
  • Class Rating: RK1
  • Certification: UL 248-12 File E2137, CSA C22.2 No. 248.12
  • Family: Amp-Trap 2000
  • Country of Origin: Mexico


Product Identification
  • UPC: 782001991593
  • GTIN: 00782001991593
