Cutler Hammer A550X100E-1 - Medium Voltage Fuse 100A (5500V, 63kA AIC)
Cutler Hammer A550X100E-1 - Medium Voltage Fuse 100A (5500V, 63kA AIC)
Cutler Hammer A550X100E-1 - Medium Voltage Fuse 100A (5500V, 63kA AIC)
Cutler Hammer A550X100E-1 - Medium Voltage Fuse 100A (5500V, 63kA AIC)

Cutler Hammer A550X100E-1 - Medium Voltage Fuse 100A (5500V, 63kA AIC)

Cutler Hammer
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer A550X100E-1 is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power systems. It features a 5500V AC voltage rating and a 100A current rating, providing reliable overcurrent and short-circuit protection. The fuse is constructed as a single-barrel unit with ferrule connections, measures 3 inches in diameter with a 12-inch clip center spacing, and has a robust design weighing 11 lb. It complies with industry standards for Class E fuses and offers an interrupting rating of 63kA at 5.5kV. Typical applications include motor circuits, transformers, and feeder protection in medium voltage switchgear and industrial control equipment.

Key Features & Specifications
  • Type: Medium Voltage Current-Limiting Power Fuse, Single Barrel, Ferrule Connection
  • Voltage Rating: 5500V AC
  • Current Rating: 100A
  • Dimensions: 3" Diameter, 12" Clip Center
  • Standards: Class E Rating
  • Applications: Motor Protection, Transformer Protection, Feeder Circuits, Industrial Switchgear
  • AIC rating: 63kA @ 5.5kV
  • Connection: Ferrule
  • Barrels: 1
  • Class Rating: E
  • Weight: 11 lb
  • Family: CS-3 Series
  • Type: A055
  • Item Subcategory: Medium Voltage
  • Manufacturer: Eaton


Product Identification
  • Manufacturer Part Number: A550X100E-1
