Mersen A2D9R - Class RK1 Fuse 9A 250V (200kA AIC)

Mersen A2D9R is a Class RK1 low-voltage current-limiting fuse designed for circuit protection in industrial electrical systems. This 250VAC/DC-rated fuse features a 9A current rating with a 200kA interrupting capacity at 250V, housed in a compact 0.56" diameter x 2" barrel constructed to meet stringent safety standards. Certified to CSA C22.2 No. 248.12 and UL 248-12 (File E2137), the Amp-Trap 2000 series fuse provides reliable protection for motor circuits, transformers, and power distribution equipment.

Key Features & Specifications

• Type: Current-limiting fuse with time-delay characteristics (A2D-R)
• Voltage Rating: 250V AC/DC
• Current Rating: 9A
• Dimensions: 0.56" diameter x 2" length
• Standards: CSA C22.2 No. 248.12, UL 248-12 (File E2137)
• Applications: Motor circuits, transformers, industrial power distribution
• Class Rating: RK1
• AIC rating: 200kA@250V
• Barrels: 1

Product Identification

• UPC: 78200199079
• GTIN: 00782001990794
