Mersen A2D8/10R - Class L Fuse 8A 250V (200kA AIC Rating)

Mersen A2D8/10R is a Class L low-voltage fuse designed for high-interrupting capacity circuit protection in industrial applications. It features a 250V AC/DC voltage rating with an 8A current rating and provides reliable overcurrent protection with a 200kA interrupting rating at 250V. The fuse construction utilizes a single-barrel design with a 2.5-inch diameter and compact 2-inch length, weighing 5.19 lb for robust performance. This fuse meets CSA C22.2 No. 248.12, DC UL 248, and UL 248-12 File E2137 standards, ensuring compliance with industrial safety requirements. Typical applications include motor branch circuit protection, service entrance equipment, and industrial power distribution systems where high fault current interruption is critical.

Key Features & Specifications

• Type: Class L low-voltage fuse, single-barrel construction
• Voltage Rating: 250V AC/DC
• Current Rating: 8A
• Dimensions: 2.5" diameter x 2" length
• Weight: 5.19 lb
• Standards: CSA C22.2 No. 248.12, DC UL 248, UL 248-12 File E2137
• Applications: Motor branch circuit protection, service entrance equipment, industrial power distribution
• AIC rating: 200kA@250V
• Class Rating: L
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 78200199061
• GTIN: 00782001990619
